Product Name:
7 Inch Touch Screen Digitizer For Toyota JBL Navigation LQ070T5GA01 Made By Denso
Product Attribute:
Application:
Toyota JBL
Product Description:
7" Touch Screen Digitizer for Toyota JBL Navigation LQ070T5GA01 86120-0C330 Made by Denso 08-14
Compatible with the following Toyota vehicles:
Sienna (2011-2014)
Sequoia (2008-2012) will not work on 2013 up sequoia
Tundra (2008-2013)
Camry (2007-2009)
Venza (2009-2012)
4 Runner (2010-2013)
Prius (2010-2011)
Highlander (2008-2014) Will not fit for 8" navigation screen of Highlander
Screen Part Number:
LQ070T5GC01, LQ070T5GA01, LQ0DA52115, LQ0DAS1387
Toyota Part No:
86120-0C330, 86120-0C220, 86120-0C230, 86120-06390, 86120-33A10, 86120-06510, 86140-0T061, 86120-35530, 86120-48M70, 86120-08250, 86120-47390
E7011, E7012, E7021, E7022, E7024, E7026, E7027, E7028
Features & Specifications:
- High quality and good operation.
- Fit for Toyota JBL Navigation Made by Denso.
- Size: 7 inch (169*99mm).
- Interface: 8-Pin.
- Thickness: 1.5mm
- Main material: Glass.
- Working Voltage: 5V.
- Replacing touch screen: Loss of response to touch commands, scratches, cracks, dead pixels, or the polarized protection is wearing off.
Attention:
1. The cable interface of the touch screen is 8-pins.
2. Installation instructions not included. Tool not included.
3. It is only a touch panel, not including a LCD display.
4. Please check the exact dimensions of the touch screen before buying to make sure that it is fit for your device. If there is any question/problem, please feel free to contact us.
5. There is a layer of protective film on the surface of the panel. Please remove the protective film before using it.
Package Included:
1PCS 7" Touch Screen Digitizer for Toyota JBL Navigation Made by Denso 08-14
