Product Name:
8.4 inch Touch Screen Digitizer for Dodge Ram 1500 UAQ UAS Uconnect Radio Navigation
Product Attribute:
Application:
Dodge Ram
Product Description:
8.4" Touch Screen Digitizer for Dodge Ram 1500 UAQ UAS Uconnect Radio Navigation Made By Delphi
Compatible with the following vehicles:
Dodge Ram 1500 UAQ UAS Uconnect Radio Navigation Made By Delphi (2019-2020)
According to Radio Navigation Part Number:
P68292209AA, P68292209AB, P68292209AC, P68292209AD, P68292209AE, P68292209AF, P68292209AG, P68428588AA, P68399198AF
For Model: VP2_8.4 DT SXM, VP2_8.4DTSXM, VP284DTSXM,
According to Screen OEM Number:
LQ084X5LX01
PN: 28488136
Features & Specifications:
- 100% new and high quality, good operation.
- Size: 8.4 inch (184.5*141.5mm).
- Cable Interface: 60Pin.
- Thickness: 1.5mm
- Length of FPC (flexible print circuit): 41.5mm.
- Working voltage: 5V.
- Main material: Glass.
- TFT (LCD) technology.
- Replacing touch screen: Loss of response to touch commands, scratches, cracks, dead pixels, or the polarized protection is wearing off.
Attention:
1. The cable (FPC) interface of the touch screen digitizer is 60 pin.
2. Installation instructions not included. Tool not included.
3. It is only a touch panel, not including a LCD display.
4. Retain screen vibrate function.
5. Please check the exact dimensions of the touch screen before buying to make sure that it is fit for your device. If there is any question/problem, please feel free to contact us.
6. There is a layer of protective film on the surface of the panel. Please remove the protective film before using it.
Package included:
1x Touch Screen Glass Digitizer
We selling Touch Screen Glass Digitizer only, the navigation unit in picture as an application scenario instruction, not included for sale.
