Frontera Light Through Motor X23 168B For GMC GM Cadillac Buick Chevrolet Chevy
Opel (GM)
Frontera light through motor X23 168B for GMC GM Cadillac Buick Chevrolet Chevy
Product:
Frontera light through motor X23 168B for GMC GM Cadillac Buick Chevrolet Chevy Pontiac (2001-2006)
Same application as X27 168
Summary of features:
- 1/3° resolution per step - low current consumption - small dimensions: Ø 30 x 9 mm - can be directly driven by a micro-controller - large temperature range: -40° C ÷ 105° C - high rotation speed up to 600 °/s - qualified for automotive applications
It is a special motor that is most suitable for pointer lighting. The motor uses a hollow transparent shaft to direct the light into the rotating pointer shaft vertically, thus providing consistent illumination for any angle of the pointer. The guiding part of the light is wrapped with metal, which avoids the typical scattering of light issue of transparent shaft in front of and behind the dial. This metal shaft solution ensures a perfect connection between the motor and the plastic pointer.
