Product Name:
Touch Screen Digitizer For Toyota Prius Hybrid Sedan 2004-2009
Product Attribute:
Application:
Toyota Prius
Product Description:
Touch Screen Digitizer for Toyota Prius Hybrid Sedan 2004-2009
Application:
Toyota Prius Hybrid Sedan Will fit both Navigation and Non-Navigation MFD (2004-2009)
OEM Number: 86110-47210, 86110-47220, 86110-47230, 86110-47081, 86110-47080, 86110-47070
If you have ordered can require us for Removal Instructions of Prius Navigation Unit.
Also Applied On:
Lexus GS300 GS350 GS430, GS450h (2005-2009)
Lexus IS250 IS300 IS350, IS-F (2006-2009)
Lexus GX GX470 Truck, Suv (2005-2009)
Lexus RX300, RX330, RX350, RX400, RX400H (2004-2009)
LX470 ES350 (2007-2011)
Screen Part Number:
LTA070B510F, LTA070B511F
Features & Specifications:
- High quality and good operation.
- Fit for both Navigation and Non-Navigation MFD
- Size: 7.3 inch (170*107mm).
- Length of FPC (flexible print circuit): 50mm
- Interface: 4-Pin.
- Thickness: 1.8mm
- Main material: Glass.
- Working Voltage: 5V.
- Replacing touch screen: Loss of response to touch commands, scratches, cracks, dead pixels, or the polarized protection is wearing off.
Attention:
1. The cable interface of the touch screen is 4-pins.
2. Installation instructions not included. Tool not included.
3. It is only a touch panel, not including a LCD display.
4. Please check the exact dimensions of the touch screen before buying to make sure that it is fit for your device. If there is any question/problem, please feel free to contact us.
5. There is a layer of protective film on the surface of the panel. Please remove the protective film before using it.
Package Included:
1PCS 7.3" Touch Screen Digitizer for Toyota Prius Hybrid Sedan 2004-2009
