Product Name:
Touch Screen Digitizer For Acura MDX TLX And Honda Odyssey Radio Stereo 7
Product Attribute:
Application:
Acura MDX TLX, Honda Odyssey
Product Description:
7" Touch Screen Digitizer for Acura MDX TLX, Honda Odyssey Radio Stereo
Compatible with the following vehicles:
Acura MDX (2014-2016)
Acura TLX (2015-2017)
Honda Odyssey (2014-2016)
The double ribbon cable screen is from OEM factory and retain screen vibrate function.
We selling is single ribbon cable screen rebuild at aftermatket factory and does not support screen vibrate function.
Radio Navigation Monitor OEM Number:
39540TZ3A220M1
39540TZ3A150M1
39540TZ3A140M1
39540TZ3A130M1
39540-TZ3-A220-M1
39540-TZ3-A150-M1
39540-TZ3-A140-M1
39540-TZ3-A130-M1
According to Screen OEM Number:
C070VVN02
Features & Specifications:
- 100% new and high quality, good operation.
- Size: 7 inch (167*109mm).
- Cable Interface: 4-Pin.
- Thickness: 1.5mm
- Length of FPC (flexible print circuit): 60mm.
- Working voltage: 5V.
- Main material: Glass.
- TFT (LCD) technology.
- Replacing touch screen: Loss of response to touch commands, scratches, cracks, dead pixels, or the polarized protection is wearing off.
Attention:
1. The cable (FPC) interface of the touch screen digitizer is 4-pin.
2. Installation instructions not included. Tool not included.
3. It is only a touch panel, not including a LCD display.
4. Does not retain screen vibrate function.
5. Please check the exact dimensions of the touch screen before buying to make sure that it is fit for your device. If there is any question/problem, please feel free to contact us.
6. There is a layer of protective film on the surface of the panel. Please remove the protective film before using it.
Package included:
1x Touch Screen Glass Digitizer
